Model BIA mechanical seal

产品简介：
Double ended / unbalanced / arbitrary direction / rubber bellows

Operating parameters:
The pressure in the seal cavity: less than 0.6Mpa, the seal cavity temperature: -20 ~150 DEG C, line speed: less than 10m/Sec and the sealed medium: water, oil, weak corrosive medium, cheap, widely used. The dynamic and static ring material: resin (metal) graphite, silicon carbide, alumina, hard alloy.
